Square picket Flat Top Garrison Fence Panels 2100mm*2450mm Height 25mm Upright Spacing 100mm Powder Coated Black

Name: Square picket Flat Top Garrison Fence Panels 2100mm2450mm Height 25mm Upright Spacing 100mm Powder Coated Black
Brand: Garrison Fencing
Price: 38.88 USD

Square picket Flat Top Garrison Fence Panels 2100mm*2450mm Height 25mm Upright Spacing 100mm Powder Coated Black Manufactures

Brand Name : Garrison Fencing

Model Number : Garrison-1200mm-1500mm-1800mm-2100mm-2400mm

Certification : AS/NZS1163& AS/NZS4506-1998

Place of Origin : New Zealand And Australia Design

MOQ : 100

Price : 38.88$

Payment Terms : TT 30% deposit balance 70% at sight of done cargo

Supply Ability : 5000

Delivery Time : 7 days

Packaging Details : Metal Pallet With Plastic Jacket

Materials : Q235

Color : Black and Grey or other

Dimensions : 1800mm x 2400mm ,2100mm x 2400mm or Customized

Salt Spray Testing : Pass

Treatment : Powder Coated ,Hot Dipped Galvanized

Technical : Punch Pipes and Welding etc

Nick Name : Steel Fence ,Steel Tubular Fence ,Steel Spear Fence,Garrison Fence,ornamental steel fence

Upright Pipes : 25mm x 25mm x 1.20mm

Rails : 40mm x 40mm x 1.60mm

Post : 65mm x 65mm x 2.00mm x 3000mm

Popular : Powder Coated Stain Black

Apllication : Garden Fence, Farm Fence, Residential Fence, Highway Fence, Railway Fence, Balcony Fence, Airport Fence, Stadium Fence, Municipal Fence, Bridge Fence, Stair Fence, Air-Condition Fence

Contact Now

**Square picket Flat Top Garrison Fence Panels 2100mm*2450mm Height 25mm Upright Spacing 100mm Powder Coated Black**

Steel picket fencing/steel hercules fence panel/garrison fence panel specifications:

Size:1200*2400mm/1500*2400mm/1800*2400mm/2100*2400mm/2400*2400mm

Rails:40*40*1.6mm Pickets:25*25*1.2mm

Gap: 105mm/110mm/115mm

Notes:

Galvanizing thickness to be G90/G60 and be galvanized on both sides of the tube eg inside and outside

Steel tube to have minimum yield strength of 350MPA

Zinc repair on weld Seem of all RHS tube at the time of being formed

Powder Coating

Minimum thickness 80um

Powder be to use Akzo Nobel powder

Panels are not touched up after powder coating is there are any marks they need to be powder coated

Manufacture

Use silicon bronze wire require to be used for all fabrication welding (see attached details of welding wire)

Welding line to be minimum 10mm

Panels made to attached specifications

Square picket Flat Top Garrison Fence Panels 2100mm*2450mm Height 25mm Upright Spacing 100mm Powder Coated Black

Square picket Flat Top Garrison Fence Panels 2100mm*2450mm Height 25mm Upright Spacing 100mm Powder Coated Black Images
